01
Multi-source compatibility
Accepts PV, wind, grid, and diesel with AC/DC dual-bus coordination for diverse room power needs.
Base Station Equipment Room Energy Scenario
The base-station equipment-room energy scenario covers a full range of telecom power gear, supports PV and wind input, and builds a “renewables + grid + storage” hybrid distribution system for 24/7 room power and green, energy-efficient site operation.
Solution Positioning
This integrated hybrid energy package for base-station rooms covers indoor rooms and outdoor tower sites with a full power-hardware lineup. It accepts PV, wind, grid, and diesel inputs coordinated with storage batteries—fitting macro rooms, mountaintop rooms, coastal rooms, and more. Automatic multi-source switching and intelligent energy control solve unstable supply, high consumption, and complex operations in one stop.
02
Full hardware portfolio
In-house indoor/outdoor hybrid power cabinets, integrated power systems, and stacked-PV MPPT controllers—combined modularly as needed.
03
Uninterrupted stability
Storage peak-shaves and fills valleys; on grid loss, renewables or diesel switch seamlessly to keep telecom gear running.
04
Wide scenario fit
Wide-temperature, high-protection gear for urban, island, and mountain rooms with convenient retrofit installation.
Applicable Site Types: Mountaintop macro base-station rooms / Coastal telecom equipment rooms / Urban aggregation rooms / Remote mountain integrated rooms
System Operation Logic
PV and wind feed DC onto the DC bus, supplying telecom loads first and storing surplus in the battery bank.
Grid and diesel gensets connect to the AC bus as backup and can switch in automatically to top up supply.
The base-station energy cabinet coordinates both AC and DC buses and intelligently allocates multi-source output.
When wind/solar output is low, storage discharges; multi-source linkage keeps telecom equipment online.
Find the Right Energy Solution for Your Telecom Site
Our expert team provides customized solutions and full-lifecycle support
Related Products
View All Products
Indoor Pv Energy Cabinet
Indoor PV energy cabinet, floor-standing installation, providing clean and renewable PV energy for base station equipment, suitable for PV power distribution scenarios at communication base stations.
Mounting:Floor-standing
Energy type:Clean and renewable PV energy
Application:Power supply for communication base station equipment
Functional positioning:PV energy access and DC power distribution
IDC Server Cabinet
Standard 19/21-inch IDC floor-standing cabinet with high load capacity and high ventilation, meeting the needs of bulk server and storage device installation in data centers.
Installation dimensions:19/21 inch
Panel material:Baosteel cold-rolled steel sheet
Static load:1000~1200KG
IP Rating:IP20
Outdoor Cab Twenty U
27U outdoor floor-standing all-in-one cabinet made of high-quality metal panels, integrating power supply, power distribution, monitoring, temperature control, batteries, and lightning protection, suitable for outdoor deployment at communication base stations.
Specifications:27U
Main Material:Premium metal sheet
Mounting:Floor-standing
Integrated Functions:Equipment, power supply, power distribution, monitoring, temperature control, batteries, and lightning protection grounding
Low Voltage Switchgear
Modular low-voltage switchgear cabinet supporting mixed installation of withdrawable and fixed units, integrating power distribution and motor control functions, suitable for industrial power distribution scenarios.
Product Dimensions:(400-1200)×(600-1200)×2200mm
Operating Temperature:-5℃～55℃
Circuit configuration:S-type 36 circuits/U-type 48 circuits
Segregation class:Form 4b (GB7251.12-2013)
Hr2000 Row Modular Data Center
Integrated single-row enclosed cold-aisle micro-module solution, combining power, cooling, monitoring, and fire suppression systems, for rapid deployment of IT computing equipment in small and micro enterprises and small equipment rooms.
Cabinet:Single row of 1-8 units, 42U/46U, maximum load of 6KW per cabinet
Cooling:In-row air conditioner cooling capacity 12.5KW, R410A refrigerant
Power distribution:UPS capacity 20KVA, lightning protection Class C
Monitoring and fire suppression:Standard 10-inch touchscreen and pipe-free FM200 (heptafluoropropane) fire suppression cabinet
Outdoor Cab Twen U
20U outdoor floor-standing all-in-one cabinet made of high-quality metal panels, integrating power supply, power distribution, monitoring, temperature control, batteries, and lightning protection, suitable for outdoor deployment at communication base stations.
Specifications:20U
Main Material:Premium metal sheet
Mounting:Floor-standing
Integrated Functions:Equipment, power supply, power distribution, monitoring, temperature control, batteries, and lightning protection grounding
Pv Distribution Box
PV AC grid-connected power distribution cabinet with integrated lightning protection, anti-islanding protection, and a visible isolation switch disconnect point, suitable for PV grid-connected power generation scenarios.
Lightning protection:Input surge arrester
Metering method:Sealed energy meter
Monitoring interface:RS485 (optional)
Safety configuration:Visible isolation switch disconnect point
Wall Mount Switch Power
Wall-mounted high-frequency switching power supply using soft-switching technology and active power factor correction, with high conversion efficiency, suitable for communication base station and small equipment room scenarios.
Mounting:Wall-mounted design, compact and lightweight
Power technology:Soft-switching technology, active power factor correction
Voltage adaptation:Wide AC input voltage range
Battery management:Online testing, temperature compensation, automatic voltage regulation
