| Product model | HJ-OFVD27-01 | HJ-OFAD27-01 | HJ-OFVD27-02 | HJ-OFAD27-02 |
| Rack Capacity | 27U, 19″ rack | |||
| Temperature Control Device | AC220V fan type (2 per group at top) | AC220V 600W air conditioning type | AC220V fan type (2 per group at top) | AC220V 600W air conditioning type |
| Dimensions (H×W×D mm) | 1500-650-650 (100mm base) | 1500-650-650 (100mm base) | 1500-650-650 (100mm base) | 1500-650-650 (100mm base) |
| Main Configuration | Double-layer 20mm EPS structure, front and rear opening doors | Double-layer 20mm EPS structure, front-opening door | ||
| Lighting | AC220V, 5W LED light, with access control switch | |||
| Shelf | 1.2mm cold-rolled steel plate, 50kg load capacity | |||
| L-shaped Bracket | 1.5mm Cold-rolled Steel Plate | |||
| Base | 1.5mm thick | |||
| Lock | Anti-theft structure, outdoor waterproof type, zinc alloy material, three-point locking | |||
| Power distribution unit | AC circuit breaker: Input 32A/2P×1, Output 10A/1P×3, Surge Arrester 40kA×1 | |||
| Packaging | Carton and Wooden Pallet | |||
Note: Specifications shown are standard values. Actual performance may vary depending on installation environment, component compatibility, and grid conditions. We reserve the right to continuously optimize design and specifications. For final technical proposals and formal quotations, please contact our sales team to request an official specification confirmation document.
