Product Overview

Built with high-strength stainless steel cabinets and precision sealing for superior waterproof and dustproof protection. Supports wide-temperature operation and high-impact resistance — ideal for telecom base stations, urban roads, campuses, and other outdoor deployments.

Material:
Cold-rolled steel sheet
Dimensions:
2000×600×300mm
Capacity:
504 cores
Tray:
42 integrated 12-core trays
Live Chat Request Brochure

Key Advantages

High Protection Rating

IP68-rated waterproof, dustproof, and corrosion-resistant for harsh outdoor environments.

Wide-Temperature Operation

Stable performance from -40°C to 60°C for deployment in extreme cold and heat.

Robust Structure

High-strength stainless steel with reinforced design for long-term equipment safety.

Flexible Configuration

Multiple sizes and interface options to meet diverse project requirements.

504 Core Equipment Side ODF Frame

Application Scenarios

Carrier Transmission Node

Carrier Transmission Node

For fiber access, convergence distribution and line management

Data Center

Data Center

Ensure stable operation of cabinets, power distribution, cabling and key equipment

Enterprise Computer Rooms & Edge Nodes

Enterprise Computer Rooms & Edge Nodes

Supports centralized deployment of small computer rooms and edge computing nodes

Low-Voltage Systems for Campus and Buildings

Low-Voltage Systems for Campus and Buildings

Supports access and management for park and building low-voltage systems

Technical Specifications

Enclosure Material Cold-rolled steel sheet Dimensions (mm) 2000×600×300
Splice Tray Capacity 504-core Weight (kg)
Standard accessories
No. Name Unit Qty No. Name Unit Qty
1 Frame Body set 1 6 Cable fixing set 1
2 Cable tie (nylon) pcs 30 7 Rubber dust ring pcs 4
3 Expansion bolt pcs 4 8
4 Splice protection sleeve pcs 504 9
5 12-core integrated tray pcs 42 10
Optional accessories
No. Name Unit Qty No. Name Unit Qty
1 SC pigtail pcs 42 3 SC adapter pcs 504
2 FC pigtail pcs 42 4 FC adapter pcs 504

Note: Specifications shown are standard values. Actual performance may vary depending on installation environment, component compatibility, and grid conditions. We reserve the right to continuously optimize design and specifications. For final technical proposals and formal quotations, please contact our sales team to request an official specification confirmation document.

Contact Us for Product Spec Sheet
