Product Overview

The 72-core ODF distribution unit is a fiber optic distribution device for standard 19-inch racks, featuring a one-piece cold-rolled steel housing with 6 integrated 12-core splicing and distribution trays built in. SC, FC, or ST fiber adapters can be selected as needed, and it supports cables from 6-18mm in diameter. The flip-open door is simple to open and lock, and it comes with a full set of accessories including cable fixtures, rubber dust rings, and nylon cable ties. It enables fiber splicing, storage, and patch cord termination, and is suitable for medium-sized fiber distribution systems such as FTTH, fiber to the building, and wireless base stations.

Material:
Cold-rolled steel sheet
Dimensions:
482×250×175mm
Capacity:
72 cores
Tray:
6 integrated 12-core trays
Live Chat Request Brochure

Key Advantages

Universal standard 19-inch rack compatibility

Standard 3U rack size, installs directly into various standard fiber optic cabinets

High-capacity modular fiber trays

6 integrated 12-core trays terminate 72 fibers together in an organized, orderly layout

Free choice of multiple adapter types

Compatible with SC/FC/ST adapters, suitable for various communication fiber optic networking projects

Compatible with various FTTH cable specifications

Accepts cables from 6-18mm in diameter, meeting various FTTH cabling needs

72 Core ODF Wiring Unit

Application Scenarios

Carrier Transmission Node

Carrier Transmission Node

For fiber access, convergence distribution and line management

Data Center

Data Center

Ensure stable operation of cabinets, power distribution, cabling and key equipment

Enterprise Computer Rooms & Edge Nodes

Enterprise Computer Rooms & Edge Nodes

Supports centralized deployment of small computer rooms and edge computing nodes

Low-Voltage Systems for Campus and Buildings

Low-Voltage Systems for Campus and Buildings

Supports access and management for park and building low-voltage systems

Technical Specifications

Enclosure Material Cold-rolled steel sheet Dimensions (mm) 482×250×175
Splice Tray Capacity 72-core Weight (kg)
Standard accessories
No. Name Unit Qty No. Name Unit Qty
1 Enclosure set 1 6 Cable fixing set 1
2 Cable tie (nylon) pcs 20 7 Rubber dust ring pcs 2
3 Large flat-head screw pcs 4 8
4 Buckle Nut pcs 4 9
5 12-core integrated tray pcs 6 10
Optional accessories
No. Name Unit Qty No. Name Unit Qty
1 SC pigtail pcs 6 3 SC adapter pcs 72
2 FC pigtail pcs 6 4 FC adapter pcs 72

Note: Specifications shown are standard values. Actual performance may vary depending on installation environment, component compatibility, and grid conditions. We reserve the right to continuously optimize design and specifications. For final technical proposals and formal quotations, please contact our sales team to request an official specification confirmation document.

Contact Us for Product Spec Sheet
