MPO Optical Cable – Multimode 12-Fiber

Product Overview

Designed for indoor high-density fiber cabling, this MPO multimode 12-fiber cable uses a 12-fiber MPO/MTP multi-fiber connector on one end and can fan out to LC connectors on the other for fast multi-fiber links to LC interface equipment. It employs OM4 50/125 μm multimode fiber for 850 nm and 1300 nm windows. The pre-terminated design significantly reduces on-site splicing and speeds installation, with customizable length and connector configuration. Stable and reliable for telecom network build-out and O&M.

Interface Type:: MPO/UPC to LC fan-out
Fiber Count:: 12 fibers (customizable 2–288)
Fiber Type:: Multimode OM4
Operating Temperature:: -40℃～+60℃

Live Chat Request Brochure

Key Advantages

High-Density Pre-Termination

12-fiber MPO/MTP consolidates multiple links in one connection, saving equipment-room cabling space

Less On-Site Splicing

Pre-terminated construction lowers installation complexity and speeds deployment

Flexible Customization

Fiber count, length, and connector layout can be customized per project

Long-Term Reliability

Operating temperature -40℃～+60℃, with up to 15-year warranty

Application Scenarios

Carrier Transmission Node

For fiber access, convergence distribution and line management

Data Center

Ensure stable operation of cabinets, power distribution, cabling and key equipment

FTTx Fiber Access

Compatible with FTTH, building fiber access and ODN branching nodes

Low-Voltage Systems for Campus and Buildings

Supports access and management for park and building low-voltage systems

Technical Specifications

Product Name	MPO Fiber Patch Cord
Interface Type	MPO/UPC to LC fan-out
Fiber Count	12 fibers (customizable 2～288 fibers)
Fiber Type	Multimode OM4
Cable Length	10 m (customizable)
Jacket Material	PVC
Application	Indoor
Operating Temperature	-40℃～+60℃
Warranty	15 years
Fiber Brand	YOFC, Corning, etc.
Package Dimensions	29.5 × 45.5 × 31.5 cm
Lead Time	1～1000 m: 3 days; larger quantities upon request

Note: Specifications shown are standard values. Actual performance may vary depending on installation environment, component compatibility, and grid conditions. We reserve the right to continuously optimize design and specifications. For final technical proposals and formal quotations, please contact our sales team to request an official specification confirmation document.
